LEI FM-4-DASH adapter suites Manual

This document describes the features and characteristics of a product of a certain brand. It includes the product name, model, brand, version number, hardware configuration, software functions, etc.

Brand: LEI
Category: Car Accessories
Document type: Installation Guide
Language: English
Pages: 5
File format: PDF
File size: 220 KB
Published: 11 July, 2012
Updated: 30 September, 2023
MD5 checksum: 1CCA1057C5F5E53F1178F64F0F2C7AB9
PDF: LEI FM-4-DASH adapter suites Manual PDF

About this manual

This document provides installation instructions for the LEI FM-4 In-Dash Adapter Kit. The kit is designed to facilitate the in-dash mounting of specific Lowrance and Eagle sonar products, including the X51, Eagle FishEasy 2, FishEasy 2 T, and TriFinder 2.

What's inside

Installation Instructions
Mounting Location Selection
Template Cutting
Unit Installation
Cable Routing
Service Information

Specifications

Compatible Products	Lowrance X51; Eagle FishEasy 2, FishEasy 2 T, TriFinder 2
Maximum Dash Thickness	0.75 inches (19mm)
Dash Cutout Dimensions	4.68" wide by 4.40" tall (119mm x 112mm)

Frequently asked questions

What tools are recommended for installation?

Recommended tools include a jig saw, drill, 1/2" drill bit, 1/8" drill bit, 1/4" nut driver or adjustable wrench.

What is the maximum dash thickness supported?

The maximum dash thickness that can be used with this mounting kit is 0.75 inches (19mm).
