This file is a manual for the Pro Logic PL-PS-4-CUL, PL-PS-8-CUL, PL-PS-16-CUL models, which introduces the features of the products, including automation and chlorination, system settings, maintenance, etc.
This document is the French installation guide for the Hayward Pro Logic pool automation system. It covers three specific model configurations: PL-PS-4-CUL, PL-PS-8-CUL, and PL-PS-16-CUL.
The guide provides step-by-step instructions for preparing the water chemistry, installing equipment, plumbing, electrical wiring, and configuring the system menu. It includes details on optional accessories such as chlorination kits, remote displays, and valve actuators. This manual is written in French.
Hayward/Goldline provides a three-year limited warranty for Pro Logic automation products installed on private residential pools in Canada and the United States.
You must use an insulated or bare copper conductor with a minimum size of 8 AWG US or 6 AWG Canada.
These elements must be connected to the equipment ground conductor using copper conductors with a minimum size of 8 AWG US or 6 AWG Canada.
