EC10QS03L is a surface mount diode with extremely low forward voltage drop, low power loss, high efficiency, and high surge capability. It is available in 30V to 100V voltage ratings.
This document is a technical datasheet for the EC10QS03L, a miniature size surface mount device (SMD) bridge rectifier manufactured by Nihon Inter Electronics Corporation. Key features highlighted include high surge capability, extremely low forward voltage drop, and low power loss with high efficiency.
The 30V through 100V types are available in this series, packaged in a 12mm tape and reel format. The datasheet provides maximum ratings, electrical characteristics, thermal data, and outline drawings for the component.
| Repetitive Peak Reverse Voltage (VRRM) | 30 V |
|---|---|
| Average Rectified Output Current (Iracss) | 1.0 A |
| Forward Current (IFams) | 1.57 A |
| Surge Forward Current (Irsm) | 20 A |
| Operating Junction Temperature Range (Tiw) | -40 to +150 °C |
| Storage Temperature Range (Tstg) | -40 to +150 °C |
| Peak Reverse Current (Irm) | 1.0 mA |
| Peak Forward Voltage (Vem) | 0.45 V |
| Approx Net Weight | 0.06g |
The operating junction temperature range is from -40 to +150 °C.
The maximum repetitive peak reverse voltage is 30 V.
The maximum average rectified output current is 1.0 A.
The operating junction temperature range is -40 to +150 °C.
