The C 221 Honey Color Analyzer is a portable microprocessor analyzer used to measure the percent light transmittance of honey compared to analytical reagent grade glycerol. The instrument directly displays the measurement result expressed in mm Pfund, and measurements are made using matched square optical cuvets with a 10 mm light path.
The Hanna Instruments C 221 is a portable microprocessor analyzer designed to measure the percent light transmittance of honey compared to analytical reagent grade glycerol. It directly displays the measurement result expressed in mm Pfund to identify the honey Pfund grade. The instrument features a dual-level LCD display and an auto-shut-off function that turns the device off after 10 minutes of non-use. It operates using two 9V batteries or a 12VDC adapter.
| Range | 0 to 150 mm Pfund |
|---|---|
| Precision | +2 mm Pfund @ 80 mm Pfund |
| Light Source | Tungsten lamp with narrow band interference filters @ 420 nm and 625 nm |
| Environment | 0 to 50°C (32 to 122°F); max 90% RH non-condensing |
| Dimensions | 230 x 165 x 70mm (9.0 x 6.5 x 2.8") |
| Weight | 640 g (22.6 oz) |
The instrument is warranted for two years against defects in workmanship and materials when used for its intended purpose and maintained according to the instructions.
The blinking 'LOBAT' indicates that the battery voltage is getting low and the batteries need to be replaced.
