The RP154x Series are CMOS-based dual output LDO regulators featuring 300mA output. RP154x features a supply current from 50μA per output, a minimum input voltage from 1.4V and the output voltage can be set from 0.8V to 3.6V (in 0.1V steps). RP154x is available in SOT-23-6 and DFN1216-8 packages. Due to the low minimum input voltage RP154x is able to extend battery life, additionally the LDO has less power dissipation by the low dropout voltage between input and output.
The RP154x Series are CMOS-based dual output LDO regulators featuring a 300mA output per channel. These regulators are designed to extend battery life due to their low minimum input voltage of 1.4V and low dropout voltage between input and output. The output voltage is adjustable from 0.8V to 3.6V in 0.1V steps.
| Output Current | 300mA per output |
|---|---|
| Minimum Input Voltage | 1.4V |
| Output Voltage Range | 0.8V to 3.6V |
| Dropout Voltage | Typ. 0.25V |
| Ripple Rejection | Typ. 70dB |
| Packages | SOT-23-6, DFN1216-8 |
The RP154x Series features a 300mA output per channel.
The device requires a minimum input voltage of 1.4V.
Yes, the output voltage can be set from 0.8V to 3.6V in 0.1V steps.
