UTC LP2950/LP2951 handbook

This datasheet provides information about LP2950/2951, including specifications, features, packages, and models.

Brand: UTC
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 7
File format: PDF
File size: 92 KB
Published: 05 July, 2012
Updated: 30 September, 2023
MD5 checksum: ECEBAB6F71AD85D1A672801DF25585AF
PDF: UTC LP2950/LP2951 handbook PDF

About this manual

This document is a technical datasheet for the UTC (Unisonic) LP2950 and LP2951 series of linear integrated circuits. These devices are monolithic voltage regulators designed with extremely low dropout voltage and low quiescent current, suitable for various applications requiring high accuracy output voltages.

What's inside

Description
Features
Ordering Information
Pin Configurations
Block Diagram
Absolute Maximum Ratings
Electrical Characteristics
Typical Application Circuit

Specifications

Output Voltage Options	2.5V, 3V, 3.3V, 3.6V and 5V
Maximum Supply Voltage	+30 V
Operating Junction Temperature	-40 ~ +125 °C
Maximum Output Current (LP2950)	100 mA

Frequently asked questions

Is the LP2951 output voltage programmable?

Yes, the output voltage is programmable for the LP2951 model.

What are the available package types?

Available packages include DIP-8, SOP-8, TO-92 (Tape Box/Bulk), and Tape Reel.
