The PCA0300A is a low-cost, high-performance phase-locked loop (PLL) for satellite modems, mobile radios, and CATV applications. It features a frequency range of 5 MHz to 275 MHz, a 1.0 ns switching speed, and -70 dBc harmonic suppression.
The document provides technical details for the Z-Communications PCA0300A Phase Locked Loop (PLL) module. Key features include a frequency range of 275 to 325 MHz with a step size of 100 KHz, designed in a cPLL-style package.
| Frequency Range | 275 - 325 MHz |
|---|---|
| Step Size | 100 KHz |
| Power Output | 44 dBm |
| Operating Temperature Range | -40 to 85 °C |
The device operates within a frequency range from 275 to 325 MHz.
