The Philips PML2852 is a CMOS high density programmable macro logic device optimized for handling wide buses, wide datapaths, and multiple-port applications. Fabricated with a high-performance EPROM process, it is designed for bus interface control, microprocessor peripheral control, memory interface, communications, instrumentation, and industrial control. The device can replace large amounts of TTL SSI and MSI logic and integrate a complete custom microcontroller.
| Max pin-to-pin delay (32-bit decoders) | 35ns |
|---|---|
| Max throughput (16-bit latches) | 33MHz |
| Max shift register rate (10-bit) | 31MHz |
| Typical internal NAND delay | 15ns |
| Max power dissipation | 525mW |
| Power down mode dissipation | 52mW |
| Number of possible foldback NAND gates | 112 |
| Number of dedicated inputs | 29 |
| Number of bidirectional I/Os | 24 |
| Number of dedicated output pins | 16 |
| Number of flip-flops | 52 |
Yes, the device includes a power down mode where power dissipation is reduced to a mere 52mW, making it ideal for laptop or pocket computers.
The device is supported by advanced SNAP and SLICE development systems, which support schematic entry, logic equations, and state equations.
