The 74HC/HCT594 is an 8-bit shift register with output register. Its features are synchronous serial input and output, 8-bit parallel output, shift and storage register have independent direct clear and clocks, 100 MHz (typ.), output capability: – parallel outputs: bus driver – serial outputs: standard, ICC category: MSI, applications: serial-to parallel data conversion, remote control holding register.
The Philips 74HC/HCT594 is a high-speed, Si-gate CMOS 8-bit parallel output device that is pin compatible with low power Schottky TTL (LSTTL). It contains an 8-bit, non-inverting, serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. Separate clocks and direct clears are provided for both the shift and storage registers.
| Maximum clock frequency | 100 MHz (typ.) |
|---|---|
| Number of parallel outputs | 8 |
| Package type | DIL plastic |
The device is suitable for serial-to parallel data conversion and as a remote control holding register.
