This is a user manual that introduces the use and features of the speaker YST-M5.
The Yamaha YST-M5 is a portable CD player and powered speaker system featuring Active Servo Technology. The document serves as an owner's guide covering setup, connections, and operation controls including volume, presence boost/cut, and power management.
Safety precautions are emphasized regarding the use of the specific AC-DC adaptor, proper placement to avoid interference with electronics or magnetic media, and cleaning procedures. Technical specifications detail the output power, frequency response, input impedance, and physical dimensions of the left and right channel units.
| Output power | 3 Wch. |
|---|---|
| Input sensitivity | 200mV |
| Input Impedance | 25 kQ |
| Output impedance | 450 ohms |
The system requires a supplied AC-DC adaptor connected to the DC 9V connection.
Connect a CD-ROM player and personal computer to Input 1 and Input 2, which are 3.5 mm jack connections.
This control allows frequency boost and cut up to ±7 dB at 10 kHz to emphasize vocals.
