The Yamaha EM-150 is a 6-channel power amplifier designed for professional audio applications. This user manual details the precautions for safe operation, explains the functions of the front and rear panel controls, and describes how to connect various audio sources and a second amplifier unit for expanded channel coverage. It includes specific instructions on using the built-in reverb, graphic equalizer, and monitor outputs.
| Channels | 6 |
|---|---|
| Output Power | 75 Wrms x 2 |
| Power Consumption | 270W (Max.) |
| Dimensions | 61.5 x 18.2 x 41cm |
| Weight | 18 kg |
| Graphic Equalizer | 7 Band |
The unit supports voltage settings of 110, 130, 220, and 240V.
The Speaker Jacks are designed for YES speakers ES-90A or ES-130.
Connect from the sub unit Rec. Out jacks to the main unit Aux. jacks or Rec. Out jacks.
It adjusts the volume of the signal from the Aux. jacks going to the Speaker and Phones outputs independently of the Master Volume.
