The Yamaha E1005 Analog Delay Line is a sound reinforcement device that provides variable time delay up to 400 milliseconds. It features both a microphone input and a switchable microphone/instrument input, each with its own level control. The unit includes controls for creating chorus, double-tracking, flanging, and other special effects, as well as a foot switch jack for convenient on/off operation. One output carries a blend of direct and delayed signal, while a second output carries delayed signal only for stereo synthesis and pure delay effects.
| Feedback | Variable, from none to 100% |
|---|---|
| Modulation Speed | 0.5 to 10Hz |
| Frequency Response | 20Hz ~ 20kHz |
| Total Harmonic Distortion | Less than 0.3% |
| Power Requirements | 120 V AC nominal, 60Hz, 12 watts |
| Net Weight | 8 pounds (3.6 kg) |
The unit provides variable time delay up to a full 400 milliseconds.
Yes, it is equipped with both a mic input and a switchable mic/instrument input.
The unit enables the creation of chorus, double-tracking, flanging, and other special effects.
A foot switch jack enables musicians to conveniently turn the effects On and Off.
