Yamaha DB-SREV1 DSP Expansion Board Installation Guide

The DB-SREV1 DSP Expansion Board is an expansion board for the SREV1 Sampling Reverberator. It can expand the functions of the SREV1.

Brand: Yamaha
Category: Other Electronics
Document type: Installation Guide
Language: English
Pages: 4
File format: PDF
File size: 1.1 MB
Published: 12 June, 2012
Updated: 30 September, 2023
MD5 checksum: 3606D13F4CF04522F81ABF68026BAC73
PDF: Yamaha DB-SREV1 DSP Expansion Board Installation Guide PDF

About this manual

This document provides installation instructions for the Yamaha DB-SREV1 DSP Expansion Board. It is intended for authorized Yamaha service engineers only. Users are advised not to install the board themselves.

What's inside

Specifications
Supplied accessories
Installation preparation
Removing the top cover
Disconnecting connectors
Removing the existing DSP board
Connecting flat cables
Reinstalling the board

Specifications

Dimensions (WxHxD)	195x15x330 mm
Weight	0. kg

Frequently asked questions

Who should install the DB-SREV1 DSP Expansion Board?

An authorized Yamaha service engineer should install the board.

What tools are required for installation?

A cross-headed screwdriver is required for removing the top cover and existing DSP board.
