DP83907 AT�LANTIC II is a Ethernet controller produced by Texas Instruments, it supports 10BASE-T, 10BASE2 and 10BASE5 Ethernet protocols, and integrates Ethernet media access control (MAC) and encode-decode (ENDEC) functions.
The DP83907 is a CMOS VLSI device designed for easy implementation of CSMA/CD local area networks. It integrates the entire bus interface for PCAT ISA bus-based systems and supports software compatibility with industry standard Ethernet adapters like Novell's NE2000. The device provides Ethernet Media Access Control (MAC), Encode-Decode (ENDEC) with an AUI interface, and 10BASE-T transceiver functions in accordance with IEEE 802.3 standards.
| Supply Voltage | Single 5V supply |
|---|---|
| Data Rate | 10 Mbit/s |
| Supported Standards | IEEE 802.3, 10BASE5, 10BASE2, 10BASE-T |
| Package | VF132A |
The device supports 10BASE5, 10BASE2, and 10BASE-T Ethernet networks.
The device operates using a single 5V supply.
Both the ACTIVITY and COLLISION LED outputs are asserted for approximately 50 ms.
