KP125W Electronic Drum Pad User Manual, includes safety instructions, product specifications, installation steps and more
The Yamaha KP125W is an electronic drum pad designed to be used with DTX series sound modules. The document covers safety precautions, unpacking contents, and detailed assembly steps including attaching legs and a footboard.
Once assembled, the manual explains how to connect the pad using the included stereo pickup cable to compatible Yamaha DTX modules (such as DTX900, DTXTREME II, and others). It also includes instructions for adjusting output levels to prevent double triggering and a troubleshooting section for common issues like low volume or unexpected sounds.
| Dimensions (assembled) | 480 x 220 x 510 mm |
|---|---|
| Weight | 6.2 kg |
| Sensing Method | Piezo trigger sensor |
| Output Interface | Standard stereo pickup jack |
To prevent double triggering, ensure the output level is not too high; if necessary, reduce the volume using the level regulator.
Yes, if used as a standalone pad without additional pads, a single-channel pickup line can be used for connection.
