Yamaha HAF3-S18(W) Speaker Bracket Owner's Manual

This manual describes the installation instructions for the Yamaha HAF3-S18(W) array frame

Brand: Yahama
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 1
File format: PDF
File size: 123 KB
Published: 11 June, 2012
Updated: 30 September, 2023
MD5 checksum: 943278B4DB159F38F8A1E425D92C7B74
PDF: Yamaha HAF3-S18(W) Speaker Bracket Owner's Manual PDF

About this manual

This document is the Owner's Manual for the Yamaha HAF3-S18(W) speaker bracket. It provides essential safety precautions, lists the contents of the package including screws, washers, and wrenches, and details the installation process for mounting the bracket to a speaker cluster.

What's inside

Safety Precautions
Package Contents
Installation Instructions
Configuration Diagrams

Frequently asked questions

What is the maximum splay angle for this bracket?

The bracket supports a maximum splay configuration of 90 degrees.

What size eye bolts are required for installation?

You must use M10 eye bolts for the installation.

What is the diameter of the holes in the rear joiner plate?

The holes in the rear joiner plate have a diameter of 406.
