This manual supplement explains the functions and specifications that have been added or changed in version 2.0 of the AW4416’s system software. It provides instructions on how to use the new functionality and detailed explanations of all items in the added pages. The MIDI data format revisions are also included. The content includes: extensions to the Quick Rec function, quick assignment of input sources to tracks, shortcut key definitions, added/modified MIDI functions, changes in the MIDI Setup page/MIDI Sync page, using control changes to operate AW4416 parameters, using parameter changes to perform AW4416 operations, transmitting internal AW4416 settings via MIDI (Bulk Dump), newly added MIDI Remote function, additional functionality for Automix, Mini YGDAI plug-in system compatible I/O card operations, backing up an I/O card, restoring to an I/O card, etc.
This document serves as a manual supplement for the Yamaha AW4416, detailing updates introduced in Version 2.0 of its system software. It covers new operational features such as extensions to the Quick Rec function and shortcut key definitions.
The guide also outlines significant enhancements to MIDI functionality, including reorganized setup pages, control change operations, bulk dump capabilities, and a new MIDI Remote function for controlling external devices.
The Quick Rec 2 page allows various input signals/input channels to be freely patched to the tracks of the recorder.
You can assign desired functions to combinations of the [SHIFT] key and other function keys (CTRL+F1-CTRL+F5) in the CTRL Key Assign page.
A 'MIDI Remote' function allows you to use faders 1-16 and [ON] keys 1-16 to control external MIDI devices.
