AP1184 is a 4A low dropout regulator produced by Anachip. It has the characteristics of adjustable and fixed output voltage. The adjustable output voltage range is 1.5V-5.0V, and the output current can reach 4A. It has good anti-interference performance and is suitable for applications that require 2.8V or lower voltage.
The Anachip AP1184 is a 5-terminal device designed to provide extremely low dropout voltages comparable to PNP regulators without the associated power dissipation disadvantages. It features an internal thermal shutdown and is available in SOP-7L, TO220-5L, and TO263-5L packages.
| Output Current | 4A |
|---|---|
| Dropout Voltage (Max) | 0.7V at 4A load current |
| Operating Junction Temperature Range | 0 to +150 °C |
| Storage Temperature Range | -65 to +150 °C |
| Input Voltage (Max) | 16V |
The AP1184-ADJ can be programmed to any voltages in the range of 1.25V to 15.5V.
It is available in SOP-7L, TO220-5L and TO263-5L packages.
Yes, it incorporates an internal thermal shutdown that protects the device when the junction temperature exceeds the allowable maximum.
