This is the owner's manual for the RX-V630RDS AV Receiver and DSP-AX630SE AV Amplifier
This document serves as the owner's manual for both the Yamaha RX-V630RDS AV Receiver and the DSP-AX630SE Digital Sound Processor. It provides instructions on getting started, including checking package contents and installing batteries in the remote control.
The guide details controls and functions such as input selection, volume adjustment, and speaker management. It covers preparation steps like speaker setup and connecting various components, including video and audio sources, antennas, and external amplifiers or decoders.
| Built-in amplifier channels | 6-channel power amplifier |
|---|---|
| Main output power (8 ohms) | 75W+75 W |
| Center channel output power (8 ohms) | 75 W |
| Rear output power (8 ohms) | 75W+75 W |
| Rear center output power (8 ohms) | 75W |
| D/A converter resolution | 96-kHz/24-bit |
Yes, it covers both units, though tuning descriptions do not apply to the DSP-AX630SE which lacks a tuner.
The remote requires four AAA (R03, UM-4) batteries.
