ADN8820 is a programmable laser driver and controller in the ADN series with four operating modes: constant laser current, constant optical output power, constant EDFA gain and constant laser power. High power efficiency: >90%
The ADN8820 is a continuous wave (CW) and Erbium-Doped Fiber Amplifier (EDFA) laser diode driver and controller designed for telecommunication systems. It provides low noise and precise current control, supporting four operational modes: Constant Current (CC), Constant Laser Power (CLP), Constant Output Power (COP), and Constant EDFA Gain (CG). The device supports both common-cathode-to-ground and common-anode-to-VDD configurations.
| Power Supply Range | 3.0 V to 5.5 V |
|---|---|
| Operating Temperature Range | -40°C to +85°C |
| High Power Efficiency | >90% |
| Output Current (PWM) | Up to 5A |
| Gain-Bandwidth Product (Linear) | 10 MHz |
The device provides output currents of up to 5A when a pair of external MOSFETs are used on the PWM amplifier.
The device operates within a temperature range of –40°C to +85°C.
The absolute maximum rating for the supply voltage is 6 V.
