The document provides essential information for identifying the specific 5975 MSD version (VL, inert, or inert XL) via serial numbers and product codes. It details critical safety warnings regarding high voltages, electrostatic discharge, hot surfaces, hydrogen safety, and chemical handling before installation begins.
Key sections cover site preparation requirements including space and weight constraints, communications needs (telephone and LAN), electrical specifications (voltage ranges and power configurations), and environmental conditions such as temperature, humidity, altitude, dust levels, and exhaust venting. The guide also addresses carrier and reagent gas requirements, laboratory supply needs, and procedures for receiving, unpacking, inspecting, and verifying the system installation.
| Voltage fluctuation limit | +5% or -10% |
|---|---|
| Category environment | Category II |
Each MSD is identified by a unique 10-character serial number located on a label on the lower left side near the front of the instrument.
Never remove a cover unless the detector, inlet, or oven are turned off to avoid contact with dangerous voltages.
The equipment must be installed in a Category II environment as defined in IEC 664.
