The ISL60002 is a high precision, low power voltage reference from Intersil. It features Intersil's proprietary floating gate analog technology, low supply voltage operation and an ultra-low operating current of 400nA. Additional features include guaranteed initial accuracy as low as ±1.0mV, @ 20ppm/°C temperature coefficient and long-term stability of <<10ppm/√1kHrs.
The ISL60002 is a precision low-power voltage reference fabricated in Intersil's Floating Gate Analog technology. It offers ultra-low current consumption (400nA) and high accuracy (±1.0mV initial) with a 20ppm/°C temperature coefficient. Designed for high-resolution data conversion systems, it supports multiple output voltages including 1.024V, 1.2V, 1.25V, 1.8V, 2.5V, and 3.3V. The device is available in 3-pin SOT-23 and 8-pin SOIC packages with temperature ranges from -40°C to +85°C or +105°C, depending on the variant. It includes ESD protection and is RoHS compliant.
| Output Voltage | 1.024V, 1.2V, 1.25V, 1.8V, 2.5V, 3.3V |
|---|---|
| Initial Accuracy | +1.0mV, +2.5mV, +5.0mV |
| Supply Voltage Range | 2.7V to 5.5V (for -10 to -25 variants), 3.5V to 5.5V (for -33 variant) |
| Supply Current | 400nA (typical) |
| Temperature Coefficient | 20ppm/°C |
| Long-Term Stability | <<10ppm/V1kHrs |
| Operating Temperature Range | -40°C to +85°C (standard), -40°C to +105°C (ISL60002-33) |
| Package | 3 Ld SOT-23 and 8 Ld SOIC |
The ISL60002 offers reference voltages of 1.024V, 1.2V, 1.25V, 1.8V, 2.5V, and 3.3V.
The initial accuracy options are +1.0mV, +2.5mV, and +5.0mV.
The standard operating temperature range is -40°C to +85°C; the ISL60002-33 variant supports -40°C to +105°C.
The ISL60002 consumes ultra-low 400nA operating current.
