Agilent OpenLAB Agilent Instrument Controller Installation and Configuration Guide, this guide introduces the installation and configuration steps of Agilent Instrument Controller, including installation, connection and configuration
This guide provides step-by-step instructions for installing and configuring the Agilent Instrument Controller (AIC) for use with Agilent OpenLAB. It covers setup for AIC 5000, Rev A, and Rev B models, including hardware connections, software installation, and factory reset procedures. The guide assumes the user has a computer with Internet Explorer and .NET Framework installed and includes network and power configuration details.
| Dimensions (Height) | 3.95 inches (10.3 cm) |
|---|---|
| Weight | 21 lb (9.53 kg) |
| Operating Temperature | 50° to 95° F (10° to 35° C) |
| Power Supply | 115 V 230 V |
| Rated Voltage Range | 100127 VAC / 200240 VAC |
| Rated Line Frequency | 5060 Hz |
| Power Output | 185 W |
| Rated Input Current (maximum) | 5 A @ 100 VAC / 2.5 A @ 200 VAC |
You need a computer with Microsoft Internet Explorer and .NET Framework 1.1 or 2.0 installed, and the network crossover cable provided with the AIC.
Turn on the AIC, plug in the Reset to Factory Adapter into any USB port, wait for the beeping, then remove the adapter. The AIC will restart and complete the reset.
After a reset to factory, the IP address of the AIC will be reset to 192.168.1.1.
