MCP73841/2/3/4 is a linear charge management controller with high-accuracy preset voltage regulation, programmable charge current, safety charge timers, etc. It is suitable for applications such as lithium-ion/lithium-polymer battery chargers, personal data assistants, cellular telephones, hand-held instruments, cradle chargers, digital cameras, MP3 players.
The MCP7384xX family of devices are highly advanced linear charge management controllers designed for space-limited, cost-sensitive applications. The family includes the MCP73841 and MCP73842, which offer complete stand-alone solutions with cell temperature monitoring in 10-pin MSOP packages, and the MCP73843 and MCP73844, which omit the temperature monitor and are available in 8-pin MSOP packages.
These controllers provide high-accuracy preset voltage regulation options of 4.1V, 4.2V for single-cell applications, and 8.2V, 8.4V for dual-series cell applications. Key features include programmable charge current, safety timers, automatic end-of-charge control, preconditioning for deeply depleted cells, and automatic power-down when input power is removed.
| Supply Input Voltage Range | 4.5V to 12V (MCP73841/3); 8.7V to 12V (MCP73842/4) |
|---|---|
| Operating Temperature Range | -40°C to +85°C |
| Package Types | MSOP-10 (MCP73841, MCP73842); MSOP-8 (MCP73843, MCP73844) |
| Charge Termination Threshold | 4mV to 10mV (Vpop - Vsense) |
| Fast Charge Safety Timer Period | 1.2 to 1.6 Hours |
The available options are 4.1V and 4.2V.
The available options are 8.2V and 8.4V.
The MCP73841 and MCP73842 models provide optional continuous cell temperature monitoring.
The maximum junction temperature is not explicitly listed in the provided text, but storage temperature ranges from -65°C to +150°C.
