STK17TA8 is a 128K x 8 AutoStore™ nvSRAM event data recorder with Real-Time Clock that combines the data integrity of Simtek nvSRAM with a full-featured RTC.
The Simtek STK17TA8 is an integrated circuit combining a 1 Mbit nonvolatile static RAM (nvSRAM) with a full-featured real-time clock. It utilizes Simtek's QuantumTrap™ technology to ensure reliable data storage, allowing the SRAM to be read and written unlimited times while independent nonvolatile data resides in dedicated elements.
The device supports operation at 3V (+20%, -10%) and offers access times of 25ns, 35ns, or 45ns. Key features include a programmable alarm function, a watchdog timer for process control, and capacitor or battery backup options to maintain the RTC supply voltage during power loss.
| Memory Size | 1 Mbit (128K x 8) |
|---|---|
| Access Times | 25ns, 35ns and 45ns |
| Data Retention | 100-Year |
| Operating Voltage | 3V (+20%, -10%) |
The device uses Simtek's QuantumTrap™ technology to produce reliable nonvolatile memory elements.
Yes, the SRAM can be read and written an unlimited number of times.
The device supports either a capacitor or battery backup for the Real-Time Clock supply voltage.
