The ICL8069 is a 1.2V temperature-compensated voltage reference that achieves excellent stability and low noise. It is suitable for applications such as analog-to-digital converters, digital-to-analog converters, threshold detectors, and voltage regulators.
The ICL8069 is a low-voltage reference utilizing the bandgap principle to achieve excellent stability and low noise at reverse currents down to 50µA. It features a guaranteed temperature coefficient of 10ppm/°C max, low bias current, and freedom from oscillation.
| Output Voltage (IR = 50µA) | 1.20 V to 1.25 V |
|---|---|
| Temperature Coefficient | 10ppm/°C max |
| Low Bias Current | 50µA min |
| Reverse Dynamic Impedance | 0.6 Ω |
| Forward Voltage Drop | 0.7 V to 1 V |
The temperature coefficient is guaranteed to be a maximum of 10ppm/°C.
The device operates with a low bias current down to a minimum of 50uA.
