The TLV247x series are low power, high performance, CMOS operational amplifiers that offer 2.8 MHz of gain-bandwidth product, input bias current of only 2.5 pA, and output drive capability up to ±35 mA.
The TLV247x is a family of CMOS rail-to-rail input/output operational amplifiers designed for low-power applications requiring high AC performance. These devices consume just 600 µA per channel while offering a 2.8 MHz gain-bandwidth product and the ability to swing to within 180 mV of each supply rail.
| Supply Current | 600 µA/Channel |
|---|---|
| Gain-Bandwidth Product | 2.8 MHz |
| Output Drive Capability | +35 mA at 500 mV |
| Supply Voltage Range | 2.7 V to 6 V |
| Input Offset Voltage | 250 µV (typ) |
| Operating Temperature Range | -40°C to 125°C |
The devices consume just 600 µA per channel.
Yes, it is qualified in accordance with AEC-Q100.
The absolute maximum rating for supply voltage is 7 V.
