This document prohibits the use of the ZHX1000 SIR transceiver
This document provides product specifications for the ZiLOG ZHX1000 SIR transceiver, a device designed to support IrDA Data standards (2.4-115.2 Kbps), LocalTalk, and Sharp ASK modes. The transceiver integrates an infrared emitting diode, a PIN photodiode detector, and driver/receiver circuitry in a single miniature package.
| Supply Voltage Range | 2.4 to 5.5 V |
|---|---|
| Typical Power Consumption | 90 uA at 3 V |
| Operating Temperature Range | -30 °C to +85 °C |
| Eye Safety Standard | IEC 825-1 Class 1 |
No, the document explicitly warns against using the ZHX1000 SIR transceiver in new designs.
The device supports a minimum data rate of 2.4 Kbps according to IrDA SIR specifications.
