This document introduces the features and characteristics of CORCOM EMC series filters. This series of filters is a dual-stage filter with a maximum current rating of 30 amps. It has high performance and low cost, and is suitable for applications that require high performance.
The Tyco Electronics EMC Series consists of compact, cost-effective dual-stage RFI (Radio Frequency Interference) power line filters designed to reduce conducted noise. These filters are developed to meet CISPR requirements in Europe and FCC specifications in the USA. The series is noted for having a maximum current rating of 30 amps, which is higher than similar catalog products.
| Maximum current rating | 30 amps |
|---|---|
| Operating frequency | 50/60 Hz |
| Rated voltage (max) | 250 VAC |
| Hipot rating line-to-ground | 2250 VDC |
| Certification UL | Recognized |
The EMC Series has been developed to reduce conducted noise to acceptable limits for equipment that must comply with CISPR requirements in Europe and FCC specifications in the USA.
The design has a maximum current rating of 30 amps, which is higher than any similar catalog product.
The hipot rating is 2250 VDC for line-to-ground and 1450 VDC for line-to-line.
