Murata O05E-5 Chip Coil Catalog

This is a catalog of Murata's LQ-series chip coils. It introduces the product's features, applications, specifications, etc.

Brand: Murata
Category: Other Electronics
Document type: Product Leaflet
Language: Chinese
Pages: 54
File format: PDF
File size: 687 KB
Published: 05 June, 2012
Updated: 30 September, 2023
MD5 checksum: 1959A91B7AEFDE5398FBE44ACD636CB4
PDF: Murata O05E-5 Chip Coil Catalog PDF

About this manual

The document is a product guide for the Murata LQ-series of chip coils. These compact, high-performance inductors feature innovative coil and case structures that result in low DC resistance and outstanding high-frequency characteristics. The series is designed to facilitate component selection for individual circuit requirements across general frequency ranges. This manual is written in Chinese.

What's inside

Chip Coil Series Overview
Part Numbering System
LQH1N/LQH3N/LQH4N Specifications
LQG11N Multilayer Chip Coil
Typical Electrical Characteristics
Dimensions and Packaging

Specifications

Inductance Range (LQH1N)	0.15mH to 10mH
Operating Temperature Range	-20°C to +85°C
Structure Type (LQG11N)	Magnetically shielded multilayer

Frequently asked questions

What are the main features of the LQ-series chip coils?

They consist of compact, high-performance inductors with low DC resistance and outstanding high-frequency characteristics.

What applications are suitable for the LQH1N series?

The LQH1N series is suitable for portable audio-visual equipment due to its miniature size allowing parallel mounting.
