This document provides detailed information on Adam Technologies' 215 Series Circular DIN Jacks, including PC Board Mount and Panel Mount Jacks. These jacks are available in 3 to 8 positions, and offer shielded and non-shielded options.
This document provides technical details for the Adam Technologies DJ Series of circular DIN jacks. It covers three specific product lines: the DJP Series (Panel Mount) and the DJN Series (PCB Mount). The panel mount models are available in 3-position and 4-position configurations, while the PCB mount model is a 5-position jack.
The document includes detailed dimensional drawings for each series, specifying measurements such as overall height, mounting hole spacing, and pin dimensions. It also provides recommended PCB layout guidelines to ensure proper installation and soldering.
The panel cutout is 0.551 inches and the overall height is 0.630 inches.
