The LTC2704 is a highly integrated 16-bit, 4-channel DAC with a wide range of features designed to increase performance and simplify design.
Design Note 431 introduces the LTC2704, a highly integrated 16-bit, 4-channel digital-to-analog converter (DAC) designed for industrial control and automated test applications. The device offers unprecedented integration by combining four single-range voltage outputs into one package with no compromises.
The LTC2704 is a highly integrated 16-bit, 4-channel DAC designed for high-end industrial and control applications.
It provides true 16-bit performance over six software selectable ranges including OV to 5V and -10V to 10V.
All functions are controlled via an easy-to-use 4-wire SPI bus.
