The Am29F040 is a 4 megabit CMOS flash memory with a 5.0-volt operating voltage. It is characterized by low power consumption, high performance, and erasable sectors.
The AMD Am29F040 is a 4 Megabit (524,288 x 8-Bit) CMOS Flash Memory designed for in-system programming using a standard 5.0V power supply. It features a sector erase architecture with uniform 64 Kbyte sectors that can be erased individually or in any combination without affecting other blocks.
The device offers high performance with access times ranging from 55 ns to 150 ns and guarantees a minimum of 100,000 write/erase cycles. It includes embedded algorithms for automatic programming and erasing, as well as hardware sector protection to disable specific sectors from write or erase operations.
| Capacity | 4 Megabit (524,288 x 8-Bit) |
|---|---|
| Voltage Requirement | 5.0 V+ 10% |
| Sector Size | 64 Kbytes |
| Write/Erase Cycles | 100,000 |
| Maximum Access Time | 55 ns to 150 ns |
| Package Options | 32-pin PLCC, TSOP, PDIP |
No, it is designed to be programmed in-system with a standard 5.0V power supply.
The device guarantees a minimum of 100,000 write/erase cycles.
