The AAT3216 MicroPower™ Low Dropout Linear Regulator is ideally suited for portable applications where low noise, extended battery life and small size are critical.
The AnalogicTech AAT3216 is a MicroPower Low Dropout Linear Regulator designed for portable applications requiring low noise, extended battery life, and small size. It features a guaranteed 150mA output current with high accuracy (+/-1.5%) and low quiescent current (typically 70uA). The device includes a Power-OK open-drain output to signal when the voltage is in regulation.
| Output Current | 150 mA |
|---|---|
| Quiescent Current | 70 uA typical |
| Dropout Voltage | < 300 mV at 150mA |
| Output Noise | 250 uVrms/rtHz |
| Operating Temperature Range | -40 to +85 C |
The Power-OK open-drain output signals when the output voltage is in regulation.
The AAT3216 is available in a 5-pin SOT23 or an 8-pin SC70-JW package.
