This document describes the features and characteristics of the PTH05020W series non-isolated power modules, including up to 22A output current, 5V input voltage, wide-output voltage adjust (0.8V to 3.6V), efficiencies up to 96%, 155W/in³ power density, etc.
The PTH05020W is a non-isolated wide-output adjust power module designed to provide up to 22 A of output current from a 5-V input bus. It features an efficiency of up to 96% and includes industry-leading features such as Auto-Track™ sequencing, on/off inhibit, and pre-bias startup.
| Output Current | 22 A |
|---|---|
| Input Voltage Range | 4.5 V to 5.5 V |
| Output Voltage Adjust Range | 0.8 V to 3.6 V |
| Efficiency | Up to 96% |
| Operating Temperature Range | -40°C to +85°C |
The module provides up to 22 A of output current.
Yes, the output voltage can be set to any value between 0.8 V and 3.6 V using a single resistor.
Yes, it includes Auto-Track™ Sequencing to simplify supply voltage sequencing.
