CM339 is a low power quad voltage comparator produced by Champion Microelectronic Corporation. It has a maximum offset voltage of ±2mV and can be powered by a single power supply with a voltage range of +2V to +36V or by split power supplies with a voltage range of ±1V to ±18V.
The Champion CM339 is a device consisting of four independent precision voltage comparators designed to operate from a single power supply over a wide range of voltages or split supplies. It features an input common mode voltage range that includes ground, even when operated from a single supply.
Key characteristics include very low supply current (1.1mA), low input bias and offset currents/voltages, and TTL/DTL/ECL/MOS/CMOS compatible outputs. The device is available in 14-pin PDIP and SOP packages.
| Supply Voltage Range (Single) | +2V to +36V |
|---|---|
| Supply Current | 1.1mA typ (4 comparators) |
| Input Offset Voltage | 2mV max |
| Operating Temperature Range | 0°C to +70°C |
| Response Time (Large Signal) | 300 ns |
The device supports a wide single supply voltage range from +2V to +36V, or dual supplies from 1V to +18V.
Yes, the input common-mode voltage range includes ground even when operated from a single power supply.
The device has outputs that are TTL, DTL, ECL, MOS, and CMOS compatible.
