This product is a premium molded D-sub cable with features including G foil plus braid shield for maximum protection against EMI/RFI, custom stamped steel internal enclosure for 100% shielding and robust strain relief, molded backshells for durability and increased strength at cable entry point, gold plated contacts for reliable connections with repeated mating cycles, DB25 male to male connectors with lengths ranging from 2.5 ft. to 50 ft. L-com's top of the line offering of D-sub cable assemblies provides maximum protection against data corrupting EMI/RFI. These cables stand out from off the shelf D-sub cables with their double shielded cable (copper braid plus aluminum mylar foil) and custom steel internal enclosure. They are ideal for any electrically noisy environment where fans, motors or switches are nearby. Custom lengths and pinouts are available with modest minimum requirements.
The CS2N25MM-10 is a Premium molded D‑Sub cable featuring foil plus braid shielding, gold‑plated contacts, and a custom stamped steel internal enclosure for 100% EMI/RFI protection. It uses double‑shielded cable (copper braid plus aluminum Mylar foil) and molded backshells for durability.
Available in a 10‑ft length, the cable has DB25 male‑to‑male connectors, 26 AWG stranded conductors, a PVC jacket, and a light‑gray color. L‑com offers custom lengths and pinouts to suit noisy environments with fans, motors, or switches nearby.
| Shielding | Foil plus braid shield |
|---|---|
| Contacts | Gold plated |
| Cable construction | Double shielded (copper braid + aluminum Mylar foil) |
| Internal enclosure | Custom stamped steel, 100% shielding |
| Backshell | Molded, durable |
| Conductor gauge | 26 AWG stranded |
| Jacket material | PVC |
| Connector type | DB25 male‑to‑male |
| Color | Light Gray |
| Part number | CS2N25MM-10 |
It uses foil plus braid shielding for maximum EMI/RFI protection.
The cable has DB25 male‑to‑male connectors.
The cable length is 10 ft.
The part number is CS2N25MM-10.
