This product is a premium molded D-sub cable with DB25 male/female connectors and a length of 50 ft. It features G Foil plus braid shield for maximum protection against EMI/RFI. All lines are wired straight through for extending serial devices. The hex nuts on the female connectors can be removed to expose 4-40 thumbscrews. The gold plated contacts provide reliable connections with repeated mating cycles. Ideal for electrically noisy environments where fans, motors, or switches are nearby. Custom lengths and pinouts are available. This D-sub cable assembly from L-com offers exceptional protection against data corrupting EMI/RFI with its double shielded cable (copper braid plus aluminum mylar foil) and custom steel internal enclosure.
The Premium Molded D‑sub cable from L‑com is a double‑shielded assembly featuring foil plus braid shielding for maximum EMI/RFI protection. All lines are wired straight through, the contacts are gold plated, and the connectors use removable hex nuts exposing 4‑40 thumbscrews for easy mounting.
The cable is offered in a range of lengths and configurations. The 50 ft DB25 male/female version is identified as item CS2N25MF-50. Additional part numbers cover other lengths and pin counts, all built with a steel internal enclosure and a flexible PVC jacket for rugged use in noisy environments.
| Shielding | foil plus braid |
|---|---|
| Connector type | DB25 male/female |
| Contact plating | Gold plated |
| Cable construction | Double shielded (copper braid + aluminum mylar foil) |
| Mounting screws | 4-40 thumbscrews |
It uses a foil plus braid shield that provides maximum protection against EMI/RFI.
The item number is CS2N25MF-50.
Yes, the contacts are gold plated for reliable connections.
