This manual provides instructions on how to use the HP Photosmart E317 digital camera, including setup, operation, and maintenance.
This manual guides owners of the HP Photosmart E317 digital camera through initial setup, basic operation, and advanced features. It includes sections on attaching accessories, installing batteries, selecting language, and configuring date and time.
The guide also covers image quality settings, memory card usage, video recording, flash operation, and troubleshooting tips, with detailed specifications and safety information for battery handling and camera care.
| Resolution (still pictures) | 5.19 MP total, 4.92 MP effective |
|---|---|
| Video resolution | QVGA 256 × 192 at 24 fps |
| Sensor diagonal | 7.2 mm (1/2.5‑inch) |
| Lens focal length | 7.7 mm (35 mm equivalent ≈46 mm) |
| Maximum aperture (F‑Number) | f/3.5 |
| Zoom | 4× digital zoom |
| Built‑in flash | Yes, 6‑second typical recharge time |
| Internal storage | 16 MB flash memory |
| Supported memory cards | HP‑branded SD and MMC cards up to 1 GB (SD recommended) |
Attach the wrist strap to the wrist strap mount on the side of the camera.
The camera supports HP‑branded Secure Digital (SD) and MultiMediaCard (MMC) cards up to 1 GB; SD cards are recommended.
Approximately 8 images at 5 MP best quality, 10 images at 5 MP default quality, 18 images at 3 MP, and up to 95 VGA images.
