AD9980 is a high-performance 8-bit display interface with a maximum conversion rate of 95 MSPS, automated offset adjustment, various output format modes, etc.
The AD9980 is a complete, monolithic 8‑bit display interface optimized for capturing YPbPr video and RGB graphics signals. It integrates a 95 MSPS triple ADC, PLL, programmable gain and offset controls, and full‑sync processing for composite and sync‑on‑green applications.
The device operates from 3.3 V (VD) and 1.8‑3.3 V (VDD) supplies, supports multiple output formats (4:4:4, 4:2:2, DDR), and provides a two‑wire serial interface for configuration. It is supplied in an 80‑pin Pb‑free LQFP package and is rated for 0 °C to 70 °C operation.
| Resolution | 8 bits |
|---|---|
| Maximum Conversion Rate | 95 MSPS |
| Operating Temperature Range | 0 °C to 70 °C |
| Typical Power Dissipation | ≈ 950 mW |
The AD9980 can convert at up to 95 MSPS.
The device is specified for operation from 0 °C to 70 °C.
It provides 8‑bit resolution.
