STLC2150 is a Bluetooth single chip radio transceiver from ST company. It is highly integrated, supports Power Class 2 and 3 operation, and can be used in computer peripherals, modems, cameras, portable computers, PDAs, handheld data transfer devices, mobile phones, and other devices.
The STLC2150 Bluetooth® radio transceiver integrates a transceiver, PLL, antenna switch and optional power control in a single VFQFPN‑48 package. It supports Bluetooth v1.2, Power Class 1‑3 operation, and provides a unidirectional BlueRF compatible interface with JTAG serial control.
The device offers low standby current, typical transmit output of –6 dBm to +4 dBm, and operates over –40 °C to 85 °C. It complies with automotive AEC‑Q100 qualification and includes detailed pin assignments, current consumption tables, and functional block diagrams for designers.
| Package | VFQFPN‑48 (7 × 7 × 1.0 mm) |
|---|---|
| Operating Temperature Range | -40 °C to 85 °C |
| Supply Voltage (core) | 2.70 V (typ.) |
The device operates from –40 °C to 85 °C.
It is supplied in a VFQFPN‑48 (7 × 7 × 1.0 mm) package.
