The TC7106A and TC7107A are 3-1/2 digit direct-display drive analog-to-digital converters that allow existing 7106/7107 based systems to be upgraded. Each device has a precision reference with a 20ppm/°C max temperature coefficient. This represents a 4 to 7 times improvement over similar 3-1/2 digit converters. Existing 7106 and 7107 based systems may be upgraded.
The TC7106/TC7106A and TC7107/TC7107A are 3‑1/2‑digit dual‑slope integrating analog‑to‑digital converters. They provide direct‑drive LCD (TC7106) or LED (TC7107) displays, low‑noise operation, auto‑zero capability and high‑impedance differential inputs for precise measurements.
The document includes features, ordering information, package options, electrical characteristics, pin configurations, functional theory, and worldwide sales contacts for Microchip Technology Inc.
| Full‑Scale Input Range | 200 mV |
|---|---|
| Zero Input Reading | 0.0 V |
| Operating Temperature (Commercial) | 0 °C to +70 °C |
The zero‑input reading is 0.0 V.
