The TC1029 is a low power dual operational amplifier designed by Telcom Semiconductor. Its maximum supply current is 8µA and it can work with a power supply voltage range of 1.8V to 5V. It is widely used in battery operated applications, power supply circuits and consumer products.
The TC1029 is a dual, low‑power operational amplifier designed for low‑power applications. It operates from a single supply (down to Vpp = 1.8 V) or dual supplies, with a supply‑current drain independent of supply voltage. The device features an ultra‑low input bias current of less than 100 pA and a low quiescent current.
The amplifier is offered in 8‑pin MSOP, 8‑pin SOIC, and 8‑pin Plastic DIP packages, making it suitable for battery‑operated equipment. Ordering information includes part numbers for each package and temperature range specifications.
| Input Bias Current | < 100 pA |
|---|---|
| Quiescent Current | 10 µA Max |
| Supply Current (max) | 8 µA |
| Minimum Supply Voltage | 1.8 V |
| Package Types | 8‑Pin MSOP, 8‑Pin SOIC, 8‑Pin Plastic DIP |
| Operating Temperature Range | 0 °C to +85 °C |
The supply current is up to 8 µA maximum.
It can operate down to a supply voltage of 1.8 V.
The TC1029 is available in 8‑Pin MSOP, 8‑Pin SOIC, and 8‑Pin Plastic DIP packages.
