This document is the specification sheet of M392B5673FH0 M392B5170FM0 240pin VLP Registered DIMM
This datasheet describes Samsung's VLP Registered DDR3L SDRAM DIMM modules, including ordering information, key features, pin configurations, and electrical characteristics. It covers the 240‑pin VLP form factor, capacity options from 1 GB to 4 GB, and compliance with RoHS standards.
The document provides detailed specifications such as supported speed grades (DDR3‑800/1066/1333), voltage ranges (1.35 V & 1.5 V), thermal sensor accuracy, and mechanical dimensions. Pin descriptions, thermal sensor characteristics, and heat‑spreader design guidelines are also included.
| Form factor | 240‑pin VLP Registered DIMM |
|---|---|
| Die type | Based on 1Gb F‑die |
| RoHS compliance | Lead‑Free & Halogen‑Free (RoHS compliant) |
| Supported speeds | DDR3‑800, DDR3‑1066, DDR3‑1333 |
| Operating voltage | 1.35 V (1.28‑1.45 V) & 1.5 V (1.425‑1.575 V) |
It supports DDR3‑800, DDR3‑1066 and DDR3‑1333 data rates.
