This document is the installation guide for the AXIS 231D+/232D+ Network Dome Camera. It provides instructions for installing the AXIS 231D+/232D+ on your network. For all other aspects of using the product, please see the AXIS 231D+/232D+ User’s Manual.
This installation guide explains how to install the Axis 231D+/232D+ network dome camera on a LAN, including hardware mounting, power connection, and initial configuration. It references the full User’s Manual for advanced features.
Key sections cover checking package contents, mounting options (hard ceiling, drop ceiling, wall, pole), connecting the Ethernet and power cables, assigning an IP address via DHCP or static methods, using the AXIS IP Utility or AXIS Camera Management software, setting the root password, and resetting the device to factory defaults.
| Power supply | 24V AC |
|---|---|
| LED indicator – Network | Green steady for 100 Mbit/s, amber for 10 Mbit/s |
| LED indicator – Power | Green normal operation, amber during firmware upgrade |
| Digital Input pins | Pins 1‑4, connect to GND to activate |
| Transistor Output pins | Max load 100 mA, max voltage 24 V DC |
| Indoor/Outdoor use | Designed for both indoor and outdoor installations (outdoor housing required) |
If a DHCP server is present the camera receives an address automatically; otherwise it defaults to 192.168.0.90. You can set a static IP using the AXIS IP Utility or AXIS Camera Management software.
When you first access the camera, the "Configure Root Password" dialog appears. Enter the desired password twice and confirm the user name "root".
Use the supplied drill template to drill three holes, secure the bracket, slide the decoration and cover rings onto the camera, insert the fixing screw holder, connect the cables, and tighten the fixing screw.
