This PDF file is a detailed information of 1 POWER ENTRY MODULES WITHOUT LINE FILTER 66220000 product produced by Schurter company, including product types, functions, characteristics, technical parameters, other versions, installation methods, etc.
The SCHURTER 6200 series provides 1‑pole power entry modules designed for equipment protection class I. They are available in screw‑on and snap‑in mounting styles, with options for solder or quick‑connect terminals.
The modules are rated for 10 A at 250 VAC, operate from –25 °C to 70 °C, and meet IP40 protection. Detailed dimensions, derating curves, and order numbers for each variant are listed.
| Rated Current / Voltage | 10 A / 250 VAC (50 Hz and 60 Hz) |
|---|---|
| Dielectric Strength | > 2 kVAC between L‑N and L/N‑PE (1 min/50 Hz) |
| Operating Temperature Range | -25 °C to 70 °C |
| Degree of Protection | IP40 (front side) per IEC 60529 |
| Terminal Types | Solder or quick‑connect, tin‑plated |
| Panel Thickness (Screw‑on) | max 6 mm |
| Panel Thickness (Snap‑In) | 1 mm – 3 mm (various sizes) |
| Rated Power Acceptance (1‑pole) | 2 W at 23 °C |
They are rated for 10 A at 250 VAC for both 50 Hz and 60 Hz operation.
The dielectric strength is greater than 2 kVAC between L‑N and L/N‑PE (tested for 1 minute at 50 Hz).
The module can operate from –25 °C up to 70 °C.
