The SLD114VS is an index-guided AlGaAs laser diode with the excellent droop characteristics.
The SLD114VS is an index‑guided AlGaAs laser diode featuring low droop, small astigmatism and a compact 65.6 mm package. It incorporates a double‑heterostructure laser diode and a PIN photodiode for optical power monitoring, making it suitable for laser‑beam printers.
The datasheet provides optical and electrical characteristics such as a recommended output power of 3 mW, a wavelength range of 760‑800 nm, and a threshold current of 10‑45 mA. Package details, pin configuration, and typical performance curves are also included.
| Recommended optical power output | 3 mW |
|---|---|
| Threshold current (Ith) | 10 – 45 mA |
| Package size | 65.6 mm |
| Package weight | 0.39 g |
The recommended operating optical power output is 3 mW.
The threshold current ranges from 10 mA to 45 mA.
The package is 65.6 mm in size.
