S1D13305 Series LCD Controller ICs
This manual describes the S1D13305 series LCD controller ICs, covering their architecture, pin configurations, and functional blocks. It includes a block diagram, detailed pin descriptions, timing diagrams, and an instruction set for interfacing with 8080 and 6800 family microprocessors.
Additional sections cover package dimensions, power requirements, display memory interface, oscillator circuit, status flags, reset procedures, and application notes such as initialization parameters and layered display attributes. A glossary of terms and a request‑for‑information form are also provided.
| Supply voltage range | 2.7 to 5.5 V |
|---|---|
| Operating current | 3.5 mA (VDD = 3.5 V) |
| Display resolution | Up to 640 × 256 pixels |
| Internal character generator capacity | 160 characters, 5×7 pixels each |
| Package type | QFP5‑60 pin (S1D13305F00A) / QFP6‑60 pin (S1D13305F00B) |
The device operates from 2.7 V to 5.5 V.
It provides 160 characters, each 5 × 7 pixels.
The controller can drive up to a 640 × 256 pixel LCD panel.
Approximately 3.5 mA.
