The S1D15605 Series is a series of single-chip dot matrix liquid crystal display drivers that can be connected directly to a microprocessor bus.
The S1D15605 Series is a family of single‑chip dot matrix liquid crystal display drivers that connect directly to a microprocessor bus. Each chip contains an internal display RAM and driver circuits that enable low‑power, high‑resolution LCD panels for portable devices.
This manual covers the series description, features, block diagrams, pin layouts, command sets, electrical ratings, timing characteristics, MPU interface examples, and connection schemes for master‑slave configurations. It also includes detailed specifications, pad dimensions, and TCP pin assignments.
| RAM capacity | 65 × 132 = 8580 bits |
|---|---|
| Typical operating current (S1D15605D00B) | 81 µA |
| Operating voltage range | 1.8 V to 5.5 V (VDD‑VSS) |
| Operating temperature range | –40 °C to 85 °C |
| Chip size (bare) | 10.82 mm × 2.81 mm |
Each chip provides 65 × 132 bits of RAM, for a total of 8 580 bits.
The S1D15605D00B version consumes about 81 µA under the specified conditions.
The devices operate from –40 °C up to 85 °C.
