This document is about the hardware functional specification of S1D13706 Embedded Memory LCD Controller. The document describes the features and characteristics of the product.
This document provides a comprehensive functional specification for the Epson S1D13706 embedded memory LCD controller, covering its scope, features, and implementation details. It includes descriptions of the integrated frame buffer, CPU interface, display support, clock sources, and miscellaneous functions.
The specification contains pinout diagrams, detailed timing tables, register mappings, power‑save mode information, mechanical data, and references to related manuals and support contacts. It serves as a technical reference for designers integrating the S1D13706 into their systems.
| Typical VDD voltage | 3.3 V |
|---|---|
| Package | TQFP15-100 pin |
The document number is X31B-A-001-09.
It was issued on 2004/02/09.
